The 2024 Honda Transalp is a midsize adventure motorcycle developed to perform across a wide range of conditions. It is equipped with a twin-cylinder powerplant, a steel frame, adjustable ride modes, and a suite of electronic features intended to support both street-oriented and off-road applications. This model is positioned as a functional solution for riders seeking measurable reliability and ride adaptability in a middleweight platform.
Twin-Cylinder Engine Configuration with Optimized Power Delivery
The 2024 Honda Transalp is powered by a 755cc liquid-cooled parallel-twin engine operating at a 24.5-degree angle. The bore and stroke measure 87.0mm x 63.5mm, with an 11.0:1 compression ratio, producing linear torque across a broad rpm range.
The engine is equipped with Honda’s Unicam® valve train system, which places the camshaft directly above the intake valves while using rocker arms for the exhaust valves. The cylinder head includes four valves per cylinder to support adequate airflow and combustion efficiency.
Fuel delivery is managed by Programmed Fuel Injection (PGM-FI) through a 46mm throttle body. A throttle-by-wire system governs engine response and provides integration with the bike’s selectable ride modes.
Five Selectable Ride Modes for Condition-Specific Tuning
The 2024 Honda Transalp includes five ride modes—Sport, Standard, Rain, Gravel, and User. Each mode configures engine power output, throttle response, engine braking levels, ABS sensitivity, and the Honda Selectable Torque Control system (HSTC).
Sport mode delivers aggressive throttle mapping with minimal intervention from traction and braking systems. Standard mode is configured for daily road use with balanced settings. Rain mode reduces throttle response and increases traction control thresholds. Gravel mode adjusts both engine and braking inputs for unpaved surfaces. The User mode is fully customizable and allows independent adjustment of each parameter to match rider preference.
Integrated Quick Shifter and Assist/Slipper Clutch System
The 2024 model includes a quick shifter as standard equipment. This system enables clutchless gear changes in both directions and uses an internal sensor to momentarily cut ignition timing during shifts.
A slipper and assist clutch is also standard. The assist function reduces the physical effort needed at the clutch lever, while the slipper mechanism mitigates rear-wheel instability caused by sudden downshifts at higher rpm.
Chassis Design with Steel Frame and SHOWA® Suspension
The 2024 Honda Transalp is built around a steel diamond-type frame engineered for rigidity without excess mass. The structure centralizes weight distribution and provides the mounting base for long-travel suspension components.
The front fork is a 43mm SHOWA® Separate Function Fork-Cartridge (SFF-CA) inverted telescopic design, offering 7.9 inches of travel. The rear shock uses Honda’s Pro-Link® system with 7.5 inches of travel and is linked to an aluminum swingarm. Suspension geometry is set for a combination of ground clearance and road compliance.
The front brake setup consists of dual 310mm discs with two-piston calipers, while the rear uses a single 256mm disc. Two-channel ABS is integrated into both front and rear braking systems.
Wheel and Tire Specification for Mixed-Surface Operation
The 2024 Honda Transalp runs a 21-inch front wheel with a 90/90 tire and an 18-inch rear wheel with a 150/70 tire. Both wheels are spoked and tubeless-compatible, designed to maintain strength during off-road impacts.
Ergonomic Geometry and Rider Interface
The seat height is measured at 33.7 inches, designed to provide visibility and clearance in off-road terrain. An optional accessory seat lowers the ride height to 32.6 inches for improved access. Ground clearance is rated at 8.3 inches, supporting clearance over terrain changes and debris.
The rake is set at 27.0 degrees, with a trail of 4.4 inches. This geometry contributes to neutral steering input and mid-speed stability. The wheelbase is 61.5 inches, providing a balance between agility and longitudinal balance. A 42-degree steering lock allows for tight maneuvering in confined spaces.
Curb weight is 459 pounds, measured with all fluids and a full tank of fuel. The fuel tank holds 4.5 gallons.
5-Inch TFT Display with Multiple Layout Options
The instrumentation is managed through a 5.0-inch full-color TFT display. The screen includes real-time data such as speed, gear position, rpm, fuel level, trip meters, and ride mode status.
The display also integrates settings adjustments for ride modes and electronic aids. The interface is designed for visibility in both direct sunlight and low-light environments.
Additional Electronic Components and Charging Integration
The 2024 Honda Transalp includes a USB-C port as standard, located in the cockpit area for powering mobile devices, navigation units, or auxiliary electronics. This charging capability adds functional support for riders operating extended trips with electronic accessories.
Self-canceling turn signals are also included. These are managed by a sensor-based algorithm that calculates distance and lean angle to determine when to deactivate the signal automatically.
